Higher Reject Rates
Excess heat can lead to product defects, material wastage and increased rework.
Revolutionizing Textile Industry Cooling with Symphony Venti-Cooling.
Fill the form to book your free site visit
What's Preventing Your Packaging & Moulding Plant
from Operating at Peak Efficiency?
Slower Production
High temperatures can reduce production efficiency and slow down manufacturing cycles.
Rising Operating Costs
Increased energy consumption, machine maintenance and production losses add to operational costs.
Reduced Workforce Productivity
Hot and uncomfortable working conditions can cause worker fatigue, lower productivity and absenteeism.
Inconsistent Product Quality
Temperature fluctuations can affect product consistency, resulting in higher rejection rates and quality issues.
KEY BENEFITS
Operational Efficiency That Improves Profit Margins
Energy cost ↓ 80-90%*
Operational cost ↓ ₹2/sq.ft/month*
Productivity ↑ 10-20%*
Cooling coverage ↑ 2500 sq.ft/unit*
ROI < 12 months*
Disclaimer: *Performance varies depending on ambient temperature, relative humidity, plant layout, ventilation design, operating hours, equipment selection and electricity tariff.
Choose the
Perfect Cooling Unit for your Plastic Processing, Moulding & Packaging Plants
Venticool 25 U
2 side discharge option (Top & Bottom)
-
Air Delivery: 25,000 CMH.
-
Cooling Area: Up to 1600 sq. ft.
-
Efficiency: 80% cooling efficiency with honeycomb pads
-
Capacity: 70L (Top), 40L (Down) tank
-
Fan Power: 1.5 kW motor, 620 mm fan diameter
Venticool 40
2 side discharge option (Top & Bottom)
-
Air Delivery: 40,000 CMH.
-
Cooling Area: Up to 2500 sq. ft.
-
Efficiency: Four side cooling pads for superior cooling
-
Capacity: 40L (Top), 40L (Down) tank
-
Fan Power: 3 kW motor, 710 mm fan diameter
SPS 45
Side discharge option
-
Air Delivery: 40,000 CMH.
-
Efficiency: 84% evaporative efficiency with honeycomb pads
-
Capacity: 80L tank
-
Motor Power: 7.5 kW motor
SPS 75
Side discharge option
-
Air Delivery: 60,000 CMH.
-
Efficiency: 84% evaporative efficiency with honeycomb pads
-
Capacity: 100L tank
-
Motor Power: 15 kW motor
Venticool 11U
3 side discharge option (Top, Bottom & Side)
-
Air Delivery: 11,000 CMH.
-
Cooling Area: Up to 700 sq. ft.
-
Efficiency: 75% cooling efficiency with honeycomb pads
-
Capacity: 50L tank (Top & Side), 30L tank (Bottom)
-
Fan Power: 0.45 kW motor, 425 mm fan diameter
Venticool 20U
2 side discharge option (Top & Bottom)
-
Air Delivery: 20,000 CMH.
-
Cooling Area: Up to 1200 sq. ft.
-
Efficiency: 80% cooling efficiency with honeycomb pads
-
Capacity: 70L tank (Top), 40L tank (Down)
-
Fan Power: 1.1 kW motor, 620 mm fan diameter
Movicool XXL
-
Air Delivery: 20,000 CMH.
-
Cooling Area: 1500 sq. ft.
-
Efficiency: 80% cooling efficiency with honeycomb pads
-
Capacity: 70L tank
-
Motor Power: 1.1 kW motor, 620 mm fan diameter
-
Portability: Heavy duty lockable wheels for portability
Venticool 22S
Side discharge option
-
Air Delivery: 22,000 CMH.
-
Cooling Area: Up to 1300 sq. ft.
-
Efficiency: 80% cooling efficiency with honeycomb pads
-
Capacity: 70L tank
-
Motor Power: 1.1 kW motor, 620 mm fan diameter
Movicool L 200
-
Air Delivery: 8500 m³/hr*
-
Air throw distance: Up to 10m
-
Efficiency: Three side cooling pads for superior cooling
-
Capacity: 200L tank
Movicool L 125
-
Air Delivery: 8500 m³/hr*
-
Air throw distance: Up to 10m
-
Efficiency: Three side cooling pads for superior cooling
-
Capacity: 125L tank
Movicool DD 125
-
Air Delivery: 17,000 m³/hr*
-
Air throw distance: Up to 10m
-
Efficiency: Three side cooling pads for superior cooling
-
Capacity: 125L tank
Movicool XE 200
-
Air Delivery: 18,000 m³/hr*
-
Air throw distance: Up to 11m
-
Efficiency: Three side cooling pads for superior cooling
-
Capacity: 200L tank
Movicool XE 100
-
Air Delivery: 18,000 m³/hr*
-
Air throw distance: Up to 11m
-
Efficiency: Three side cooling pads for superior cooling
-
Capacity: 100L tank
